4-layer Impedance Controlled Fine Circuit Immersion Gold PCB Circuit Board

All node control modules of the smart home system are connected to the system information control center through the RS485 home control bus, following the unified home control network communication protocol to realize system data communication. 256 modules can be connected to one bus to realize various functions of home automation control. Module types include:

Wireless transceiver base station module

Mainly used in conjunction with the wireless remote control module, it is an essential accessory for the system. As a wireless transceiver base station, it transmits the information of the remote control to the system information control center through the home control network, and then transmits the instructions and short message information of the system information control center. It is transmitted to the wireless remote control through wireless radio frequency signals, which is where wireless information is converted into wired home control network information;

Relay switch control module

Low-power circuit control, controlled by high-performance solid-state relays. After receiving the command from the smart home controller, the switch of low-power appliances in the home, mainly lights (including various audio, televisions, electric curtains), controls the power of 100 watts/channel;

High-power appliance control module

It is also controlled by solid-state relays, but the power is large and there is only a single channel. After receiving the command from the smart home controller, it can control high-power appliances in the home (such as air conditioners, water heaters, etc. ), and the maximum control power of a single channel is 2500 watts;

SCR dimming control module

SCR is used for low-power loop control. After receiving the command from the smart home controller, its main function is to control the dimming of the lights in the home, with a control power of 100 watts per channel, and a dimming range of 5 levels: 0, 25, 50%, 75%, 100%;

Information exchange module

The information switch has completely changed the original switch concept. The switch information point is used to complete the function of the original switch, making the original switch function fixed and single. By setting the relevant control parameters, any control point can be controlled to achieve group control function.
